Cladded Vessels

Welcome to world-class cladded-vessels suppliers from India

Home       About us       Products       FAQ       Contact

Valve body/Bonnet Cladding
Valve body/Bonnet Cladding
Specialised Cladding using ETR (Fronius) & vertical cladding machine up to bore of 20 mm in Inconel, Hastelloy, monel Etc.
Flange Cladding
Flange Cladding
Capability of up to 2" to 120" flange dia in horizontal and vertical weld cladding machine from (Fronius)
Elbow/ Tee Cladding
Access Fittings
Cladding in Inconel 625/825, Monel. Using welding Robots (Kuka) and ETR (Fronius) for
3" NB to 42" NB including
weld edge bevel cladding
Pipe Cladding
Pipe Cladding
Size form 3" NB to 36" NB using Horizontal pipe cladding machine with Inconel 625/825, monel, Hastelloy and other exotic metals

We make custom-manufactured cladded vessels to meet unique requirements of your processes...     MORE

Crystal's cladded vessels offer extensive documentation and process information...   MORE
Commonly asked questions about cladded vessels answered...    MORE
Crystal's team of engineers offer global support for our clients, anywhere in the world...   MORE
  • Best source of cladded vessels from India
  • World class cladded vessels from India
World-class cladded vessels from India from Crystal Industrial

Our cladded vessels from India comply with the most demanding standards of strength, corrosion resistance and cost effectiveness. Generally the outer part of the vessel is made of carbon steel to withstand the inner pressures, while the inner high alloyed cladding of the vessel is meant to protect against corrosion.

We offer two types of cladding process :

  • Metallurgically cladded plates
  • Mechanically bonded vessels


Metallurgically clad plates : We use a unique patent pending process to make vessels using metallurgically clad plates. The process guarantees a tight bonding between the different materials.

We have been producing such vessels in India for reputed companies world-wide, especially in the oil and gas industry.

We offer a wide variety of size range. We produce OD's from 114.3 mm (4") up to 1 219 mm (48") in a variety of material combinations. We can supply you vessels with either an external or internal cladding.

Mechanically bonded plates : This consists of a corrosion resisting vessel that's telescopically aligned inside a vessel in carbon-manganese material. Hydraulic expansion is used to create a tight bonding between the two vessels.

We produce such vessels in a variety of size ranges, in OD's from 114.3 mm (4") up to 660 mm (26") and lengths up to 12 m without circumferential weld.

Compared with metallurgically clad vessels, our mechanically bonded vessels from India offer a wide range of material combinations for both the inner and outer vessel and remarkable price advantages. The cost saving is due to the use of economic carbon steels in conjunction with corrosion resisting steels and a low-cost production process. Also the process allows for easy assembly on site.
